Up to 1500lbs (680kg) holding force
Fits frame cutout for HES 1006 (1003)
Accommodates ¾" latch projection
Centerline faceplate included for centerline latch entry
Horizontal adjustability up to 1/8" (3mm) for misaligned frames
Vertical Adjustability for precise deadbolt and latchbolt alignment
Adjustable deadbolt keeper and deadlatch ramp
Accommodates up to 1" deadbolt (Night-latch function only, bolt will not release)
Field selectable voltage input - Accommodates 12 or 24VDC and 12 to 24VAC
Anti-tamper security screws
All installation drivers included
Low current draw (0.19 Amps @24VDC)
"Cool Keeper" Solenoid located in house prevents keeper from heating up
Plug-in wire connector
Trim plate included
Adhesive paper template included
Fail-locked (fail secure) mode standard
Optional Latch Monitor kit
Note: Fail-unlocked (fail-safe) strikes are not permitted on fire labeled doors.
Voltage Duty Sound Amps Ohms
12 VDC Continuous Silent .375 Amps 37 Ohms
24 VDC Continuous Silent .190 Amps 148 Ohms
12-24 VAC Intermittent Buzz .280 - .565 Amps 37 Ohms
Intermittent Duty = Energized less than 1 min. with Duty Ratio 1:5
Continuous Duty = Energized 1 min. or more
* Ratings are based on maximum current draw at +10°C and include initial power-up current draw.
† Nominal resistance at +25°C ± 7% tolerance
The fail secure locking mechanism shall only be installed where allowed by the local authority having jurisdiction and shall not impair the operation of the panic hardware or intended operation of the emergency exit.
5 Year Limited Warranty
UL 1034 Burglary Resistant Listed
UL 10C (3 Hour) Fire Rated
